Key: The item, no harm on wood doors, can be installed directly from the top.

Item: Top Mounting Sliding Door System

Size: Customized in length and 40*6mm for width and thickness.

Surface finishing: Black/ Brown or customized

5ft kit single door:
Roller:2pcs
Wall spacer:4pcs
Stopper:2pcs
Sliding track:5ft(1.5m)=2.5ft(0.75m)*2pcs
Anti jumper:2pcs
Floor guide:1pcs

6ft/6.6ft kit single door:
Roller:2pcs
Wall spacer:5pcs
Stopper:2pcs
Sliding track:6/6.6ft(1.8/2m)=3/3.3ft(0.9/1m)*2pcs
Anti jumper:2pcs
Floor guide:1pcs

8ft kit single door:
Roller:2pcs
Wall spacer:6pcs
Stopper:2pcs
Sliding track:8ft(2.4m)=4ft(1.2m)*2pcs
Anti jumper:2pcs
Floor guide:1pcs

Opening Method	Sliding
Door Type	wooden
After-sale Service	Online Technical Support, Free Spare Parts
Main Material	Wooden
Project Solution Capability	graphic design, 3D model design
Application	Apartment
Design Style	Rustic
Place of Origin	China
China	Zhejiang
Brand Name	Hodor Hardware
Model Number	MTK-A02
Open Style	Sliding
Position	Interior
Surface Finishing	Finished
Type	Sliding Doors
Sliding Door Type	Partition Doors
Door Material	Plywood
Material	Carbon steel and POM
Rail	2m/1.8m or customized
Surface Finish	Powder coated
Package	transport packing or customized
Packaging size	103cm x 9.5cm x 8.5cm
Load capacity	150kg
Gross weight	8kg
Color	matte black
Door Thickness	35-45mm
Product name	sliding door hardware for wardrobe

1-Top Mounting Sliding door system

Components	Picture	Material	Specification
Hanger Roller		Steel+POM+Black	Powder coating finishing or Acid finishing with painting. Wheels are made of POM, sliding more smoothly and quietly. The color of wheels matches the structure. Screws for wooden doors of 35-40mm/40-45mm thick or glass door of 8-10mm thick. All screws have been electroplated and will never rust.
Rail/Track		Steel+Black	The longest rail we can supply is 4 meters in one piece. Holes distance can be specially made as your requirement. More than 5000 sets of rail kits in stock, which can be delivered immediately after payment.
Screw & Nut		Steel+Black	Two kinds of Screw&Nut are available. One is for concrete walls and the other is for wooden ones. All Screw&Nut are packed by EPE piece by piece. It will protect Screw&Nut from impacts. After installation, the distance between door and wall should be about 2 cm. We still have longer Screw&Nut if it is needed.
Door Stopper		Black	One right version and one left. They are installed at both ends of the rail and prevent rollers from out of control. Our stopper is a perfect match with little gap in between. It is negligible completely. We still have more different new stopper designs for you.
Anti Jump		POM & Black	They are for top of doors to prevent door from jumping out of rail.
Floor Guide		POM & Black	Single Hidden Floor Guide with Screws and Anchors. For wooden doors, it needs 20*7mm gap under the doors. If you do not like this look , we have many other designs to your options.
